Additional information
| Input Voltage | 1ph 220V ± 15% |
|---|---|
| Frequency | 50 / 60 Hz |
| Rated Input Power | 7 KVA |
| Range Working Voltage | 28 V |
| No-load Voltage | 66 V |
| Range of Output Current | 20 ~ 200 A |
| Rated Input Current | 32 A |
| Diameter of Electrode | ø 2.0 ~ 5.0 mm |
| Rated Duty Cycle | 60% |
| Power Factor | ≥ 0.99 |
| Efficiency | ≥ 85% |
| Insulation Type | H |
| Protection Type | IP21S |
| Weight | 3.2 Kg |
| Dimension | 260 x 155 x 190 mm |
| IGBT Type | Single Tube |
